DFG280

  • Single-head design with 10″/250mm diameter
  • Floating head design helps the machine grind consistently even when it hits high and low spots
SKU: DFG280-BASE Category: Tags: , ,
SINGLE HEAD GRINDER

DFG280

  • Single-head design with 10"/250mm diameter
  • Floating head design helps the machine grind consistently even when it hits high and low spots
Build Your Package

The DFG280 gets into every tight spot and small corner. It is an easy must-have for every contractor and rental house!

  • Single-head design with 10″”/250mm diameter
  • Floating head design helps the machine grind consistently even when it hits high and low spots
  • Folding handle, with multiple settings for height adjustment
  • Built-in lifting handles
  • Edge-grinding on both sides thanks to removable sections of skirting
  • Wall-walker roller-bearing for better control while performing edge work
  • Tough, compact design
  • Flexible ‘morflex’ coupling reduces vibration and extends the life of the machine
  • 2″/50mm dust extraction port
  • Compatible with TMAG or any standard 10″” diamond plate tooling
Weight 1 kg
Select Region

USA, Canada

Product Description

The DFG280 gets into every tight spot and small corner. It is an easy must-have for every contractor and rental house!

  • Single-head design with 10""/250mm diameter
  • Floating head design helps the machine grind consistently even when it hits high and low spots
  • Folding handle, with multiple settings for height adjustment
  • Built-in lifting handles
  • Edge-grinding on both sides thanks to removable sections of skirting
  • Wall-walker roller-bearing for better control while performing edge work
  • Tough, compact design
  • Flexible 'morflex' coupling reduces vibration and extends the life of the machine
  • 2"/50mm dust extraction port
  • Compatible with TMAG or any standard 10"" diamond plate tooling

Technical Specifications

MODEL DFG280
Engine/Motor Type Electric
Voltage 120V
Power Output 1.5hp (1.12kW)
Cycles 60Hz
Head Speed 1725 rpm
Motor Speed  1725 rpm
Length 40" (102cm)
Width 11" (28cm)
Height 37" (94cm)
Weight 97 lbs (44kg)
Removable Weight

Build Your Package

Choose from the options below, then click 'Add to Quote Cart' button.


Boost your ROI by adding Small Grinders to your rental fleet Download
