P650E

  • Completely redesigned and re-engineered
  • Precision-balanced 3-head planetary design
  • Single-Phase or 3-Phase Electric Motor
  • 25-inch diameter (625 mm)
PLANETARY GRINDER

P650E

  • Completely redesigned and re-engineered
  • Precision-balanced 3-head planetary design
  • Single-Phase or 3-Phase Electric Motor
  • 25-inch diameter (625 mm)
Build Your Package

Product Description

The ALL NEW Predator line of concrete grinder / polishers is a PREMIUM LINE OF PLANETARY GRINDERS, newly REIMAGINED, REDESIGNED, and REENGINEERED with some of the highest standards in the industry, ensuring they are extremely reliable, productive, balanced, and easy to use for any operator. Designed to pair with the HD HEPA-filter Dust Extraction system for unbeatable dust control so your job site stays safe and compliant.

  • 3-head planetary design
  • Precise weight distribution for exceptional balance
  • Reliable belt-driven technology
  • Quick adjusting handles
  • Adjustable spring-assisted swing weights for variable head-pressure
  • Heavy-duty plate steel frame
  • Integrated transport wheel for safe mobility around the job-site
  • Variable speed control
  • Forward/reverse grinding
  • Integrated water tank
  • Bright LED work light at both front and rear of the machine
  • Adjustable dust skirt for effective dust suppression
  • Integrated lift, tie-down, and winch points

Technical Specifications

MODEL P650E
Electric Motor 230V, 60 Hz, 1 Phase
230V, 60 Hz, 3 Phase
460V, 60 Hz 3 Phase
Power Output 7.5 hp (5.6 kW) 10 hp (7.5 kW)
Variable Head Speed 1012 rpm
Water Tank Capacity 7.5 gal (28 litres)
Vacuum Port 3" (75 mm)
Grinding Force 565 lbs (256 kg)
Grinding Width 25" (625 mm)
Individual Head Diameter 9" (229 mm)
Max Height (Handle Up) 76" (1930 mm)
Min Height (Handle Down) 44" (1118 mm)
Min Length (Handle & Weights Forward) 52" (1321 mm)
Max Length (Handle & Weights Back) 83" (2108 mm)
Width 26" (660 mm)
Machine Weight 775 lbs (351 kg)

Build Your Package

Choose from the options below, then click 'Add to Quote Cart' button.


Download our Polished Concrete guide Download
