iQ228 CYCLONE

  • Integrated dust control
  • Lightweight and Portable
  • Tru-Cut measuring system
SKU: iQ228-BASE Categories: ,
7" DRY-CUT TILE SAW

iQ228 CYCLONE

  • Integrated dust control
  • Lightweight and Portable
  • Tru-Cut measuring system
Build Your Package

The world’s first 7″ dry-cutting table tile saw with integrated dust control

  • 1.25″ depth of cut
  • 18″ rip with rolling table, 24″+ rip without rolling table
  • Weighs only 36 pounds
  • 15 amp motor
  • Double fences
  • Includes a Q-Drive combo blade

Introducing the iQ228CYCLONE®, the 7” dry cut tabletop tile saw with integrated dust control and new Tru-Cut™ System. Designed for professional contractors to eliminate the problems with cutting wet, save time, and increase your profitability on tile jobs.

Tru-Cut

The Tru-Cut™ System is an integrated measurement system that provides consistent and accurate cuts for any job. Tru-Cut™ System includes:

  • Fence
  • iQ Micro Fence
  • Pre-measured Rolling Table

Next-Level Accuracy

The iQ Micro Fence allows you to dial in the exact measurement for your cut. Lock it into the table and adjust the fence to the precise cut you need.

Model

iQ228CYCLONE – 7" Dry Cut Tile Saw

Product Description

The world’s first 7" dry-cutting table tile saw with integrated dust control

  • 1.25" depth of cut
  • 18" rip with rolling table, 24"+ rip without rolling table
  • Weighs only 36 pounds
  • 15 amp motor
  • Double fences
  • Includes a Q-Drive combo blade

Introducing the iQ228CYCLONE®, the 7” dry cut tabletop tile saw with integrated dust control and new Tru-Cut™ System. Designed for professional contractors to eliminate the problems with cutting wet, save time, and increase your profitability on tile jobs.

Tru-Cut

The Tru-Cut™ System is an integrated measurement system that provides consistent and accurate cuts for any job. Tru-Cut™ System includes:

  • Fence
  • iQ Micro Fence
  • Pre-measured Rolling Table

Next-Level Accuracy

The iQ Micro Fence allows you to dial in the exact measurement for your cut. Lock it into the table and adjust the fence to the precise cut you need.

Technical Specifications

Model iQ228 CYCLONE
Voltage 120V
Total System Amperage 15A
Blade Size 7" Q-Drive Blade
Filter Type iQ Dura Bond Cartridge
Cutting Depth 1" (25mm)
Cutting Length 18" (46cm) with fence
Sound Pressure Level 86 DB(A)2
Dust Capacity 5 lbs (2kg)
Saw Weight 36 lbs (16kg)
Length 25" (64 cm)
Width 21" (54 cm)
Height 13" (33 cm)
