Standard Screed

  • High frequency vibrations are distributed evenly across entire length to produce smooth, uniform surfaces quickly and easily
  • Standard truss is 13.5″ tall and can span 40′
  • Can consolidate less than 2″ slump. Up to 12″ in depth
SKU: STANDARD-BASE Category: Tags: ,
SCREED

Standard Screed

  • High frequency vibrations are distributed evenly across entire length to produce smooth, uniform surfaces quickly and easily
  • Standard truss is 13.5" tall and can span 40'
  • Can consolidate less than 2" slump. Up to 12" in depth
Build Your Package

Product Description

High frequency vibrations distributed evenly across entire aluminum screed length to produce smooth, uniform surfaces quickly and easily. Capable of consolidating and condensing concrete with slumps of less than 2" with up to 14,000 vibrations per minute.

More

Technical Specifications

Engine Honda GX160
Truss Screed Standard
Height 13.5" (34cm)
Width 12" (30cm)
Weight 10 lbs/foot (4.5kg/30cm)
Base Section 10' (3m) 79 lbs (36kg)
Subsections 2.5' (0.75m) 27 lbs (12kg)
5' (1.5m) 46 lbs (21kg)
10' (3m) 85 lbs (39kg)
Motor Mount 53 lbs (24kg)
Max Recommended Span 40' (12m)
Average Peak Vibration 12,830 rpm
Max Compaction Depth 12" (30cm)
Self-Propelled Hydraulic Ends 166 lbs (76kg)
Hand Winch 40 lbs (18kg)
Subsections 0MS1-0120A SCREED STANDARD 10 FT SUBSECTION
0MS1-0121A SCREED STANDARD 5 FT SUBSECTION
0MS1-0126A SCREED STANDARD 2.5 FT SUBSECTION
0MS1-0131A SCREED STANDARD 1 FT SUBSECTION M2642
0MS1-0201A SCREED STANDARD SELF PROP. LH SECTION M1089
0MS1-0202A SCREED STANDARD SELF PROP. RH SECTION M1088
