RIDE-ON TROWELS

Titan78

6" lower to the ground than previous models
19" height from bottom of foot to seat
LED lights in front and rear

Build Your Package

Product Description

Our line of TITAN Ride-On concrete trowels have evolved over decades of research, testing, expert engineering and contractor feedback direct from the slab. We machine the tightest tolerances in the industry, which gives the Bartell Titan trowel arms more rigidity, better balance, and less demand for maintenance and repairs. We rely on this precision to allow for a lighter machine that is effective without needing the extra weight that many others use to compensate for poor design.

The TITAN comes in three sizes (78, 88, 96 inches), with several choices of engines, including hydraulic and propane options.Compatible with the iShine TPS system. Add concrete polishing to your list of services without adding the cost of an additional machine!

Models	Titan 78
Blade Configuration	Panning & Finishing
Engine Type	Kohler CH730	Kohler CH740	Kohler ECH749
Power Output	23hp	25hp	26.5hp
Blade RPM	180
Float Blade Size	10" x 14" (25 x 36cm)
Finish Blade Size	6" x 14" (15 x 36cm)
Combo Blade Size	8" x 14" (20 x 36cm)
Float Pan	36" (91cm)
Weight	844 lbs (383kg)
Operating Weight	880 lbs (399kg)
Length	78" (198cm)
Width	40.5" (103cm)
Height	46" (117cm)
