HD3 HEPA

  • Equipped with 3 HEPA filters which remove at least 99.97% of airborne particles down to 0.3 micrometers in diameter securing a high standard of quality and safety
  • 3 individual motor switches provide variable suction strength and power
SKU: HD3-BASE Category: Tags: ,
DUST EXTRACTORS

HD3 HEPA

  • Equipped with 3 HEPA filters which remove at least 99.97% of airborne particles down to 0.3 micrometers in diameter securing a high standard of quality and safety
  • 3 individual motor switches provide variable suction strength and power
Build Your Package

Product Description

Bartell Global's HD series dust extractors feature a two-stage filtering system with jet-pulse filter cleaning. Remove up to 99.97% of dangerous airborne particulates to keep your operators safe and your business compliant with environmental regulations. With three separate motors with individual switches, the suction can be adjusted for different applications as needed.

More

Technical Specifications

Models HD3
Volts 120 220
Amps 16 12
Inlet Diameter 2.5" (63mm) 2.5" (63mm)
Power (hp) 3.2hp 4.8hp
Air Flow (cfm) 288 356
Water lift (inches) 74 90
Pre-filter (F8) >99.5% @1.0um 48 ft2 (4.5m2) 48 ft2 (4.5m2)
HEPA Filter (H13) >99.99% @0.3um 39 ft2 39 ft2
Length 31" (78cm) 31" (78cm)
Width 23" (59cm) 23" (59cm)
Height 58" (146cm) 58" (146cm)
Weight 149 lbs (68kg) 141 lbs (64kg)
